Full-Wavelength Microplate Reader

Full-Wavelength Microplate ReaderYP-96C


【Introduction】:Youyunpu Optoelectronic Tech specializes in R&D & production of Full-Wavelength Microplate Reader, with custom services. Complete Full-Wavelength Microplate Reader models, high detection accuracy, trusted by customers.

电话图标+86 19963093538

Product Details

Instrument Introduction

The full-spectrum microplate reader is an analytical instrument based on the principle of ultraviolet-visible spectrophotometry. Equipped with high-quality optical components and precision mechanical structure, the instrument enables fast and accurate full-band scanning and fixed-point absorbance detection over a wide wavelength range (200–1000 nm). By measuring the absorbance of light at specific wavelengths by samples in microplates, the instrument performs quantitative or qualitative analysis of samples. It supports high-speed, automated detection of 96-well or larger plates simultaneously, greatly improving experimental efficiency and accuracy, making it an indispensable high-throughput basic equipment for laboratories in molecular biology, immunology, drug development and other fields.

Applicable Standards

JJG 861-2007 Verification Regulation for Enzyme-labeled Analyzers; YY/T 1529-2017 Enzyme-linked Immunosorbent Assay Analyzers.

Application Scope

The full-spectrum microplate reader is mainly used in life science and medical research. It is fundamental for protein quantification, nucleic acid concentration measurement, enzyme kinetic studies, cell viability and cytotoxicity assays, and ELISA experiments, and is widely used in laboratories of universities, research institutes and hospitals. In the pharmaceutical and biotechnology industries, it is an essential tool for high-throughput screening, efficacy and toxicology evaluation, and quality control of biological products during drug development. In agriculture and food safety, it is used to detect crop diseases, food allergens, toxins and pesticide residues. In environmental monitoring, it can be applied to analyze pollutants in water and soil, serving as an important tool for public safety protection.

Instrument Features

  1. Android 10 operating system, supporting data upload via Wi-Fi and Ethernet for fast batch data uploading.

  2. Equipped with a 10-inch high-definition touch screen and a visual graphical interface, supporting one‑click preset of experimental templates and customized workflows, greatly improving operation efficiency.

  3. Chinese/English bilingual operating system, which automatically completes detection, data storage and report generation.

  4. Quickly identifies blank wells, standards, test samples, positive/negative controls and QC wells via color block marking, supporting multi-concentration gradient control settings.

  5. Inter-well temperature uniformity error ≤ 0.5 ℃, ensuring reaction stability.

  6. Multi-level adjustable vibration speed and duration to optimize reaction mixing efficiency.

  7. Dual-beam reference optical path design, real-time compensation for environmental interference, ensuring data stability and repeatability.

  8. Supports three modes: endpoint detection, kinetic measurement and full-band spectral scanning; compatible with microplates (with/without lid) and cuvettes (including cuvette incubation function).

  9. Equipped with long-life pulsed xenon lamp, with flash life up to 1×10⁹ flashes, significantly reducing maintenance costs.

  10. Built-in self-diagnosis program: automatic optical path calibration and mechanical motion accuracy verification to ensure long-term stable operation.

  11. Centered on precision, efficiency and intelligence, this product is committed to providing more reliable enzyme immunoassay solutions for scientific research and quality control.

  12. Light source fluctuation pp value (peak intensity minus minimum intensity) < 0.5%.

  13. High-stability pulsed xenon light source.

  14. Equipped with a supervision platform; test results can be directly transmitted to the platform wirelessly.

  15. Built-in new-generation high-speed thermal printer.

  16. Data stored in image and table formats.

Technical Specifications

  1. Wavelength range: 200–1000 nm (full wavelength)

  2. Light source: xenon flash lamp

  3. Light source life: > 10⁹ flashes

  4. Bandwidth: < 2.5 nm

  5. Wavelength accuracy: ± 2 nm

  6. Wavelength repeatability: ≤ 0.2 nm

  7. Reading range: 0 ~ 4.0 Abs

  8. Function type: microplate, cuvette

  9. Microplate linearity: R² ≥ 0.999 (0.0 ~ 3.0 Abs)

  10. Microplate accuracy (450 nm): ± (1.0% + 0.003 Abs) (0 ~ 2.0 Abs]; ± 2.0% (2.0 ~ 2.5 Abs]

  11. Microplate repeatability (450 nm): CV < 0.5% or SD < 0.003 (precision mode); CV < 1.0% (fast mode)

  12. Microplate reading speed: < 8 sec (fast mode); < 28 sec (precision mode)

  13. Microplate shaking: linear, 3 adjustable speeds

  14. Incubation range: RT + 4 ℃ ~ 45 ℃

  15. Temperature uniformity (37 ℃): ± 0.5 ℃

  16. Power adapter: DC 24 V 5 A 120 W

  17. Dimensions: 333 mm × 500 mm × 274 mm

  18. Weight: 12.1 kg
