Animal Disease DetectorYP-P16

【Introduction】:Youyunpu Optoelectronic Tech specializes in R&D & production of Animal Disease Detector, with custom services. Complete Animal Disease Detector models, high detection accuracy, trusted by customers.

+86 19963093538

Product Details

Instrument Overview

The Animal/Pet Disease Detector is a device used to detect the presence of pathogens or diseases in animal biological samples. It plays a critical role in animal health monitoring, epidemic control and prevention. A wide range of animal disease detectors are available, with specific methods and technologies depending on the target diseases and sample types.

Developed by Youyunpu, this Animal Disease Detector utilizes Polymerase Chain Reaction (PCR), a widely adopted molecular biology technique. It can detect pathogen DNA or RNA in animal body fluids or tissue samples. The PCR instrument amplifies and identifies nucleic acid sequences of specific pathogens, enabling accurate diagnosis of target infectious diseases.

Instrument Structure

The real‑time reaction detector consists of four main components:

Gene Amplification Thermal Cycler System
Real‑time Fluorescence Detection System
Microcircuit Control System
Computer and application software

The two core functional modules are the thermal cycler system and the real‑time fluorescence detection system.

The gene amplification thermal cycler uses semiconductor heating and cooling to perform thermal cycling, with a working principle similar to conventional PCR instruments.
The fluorescence detection system comprises a fluorescence excitation unit, optical signal transmission components, a fluorescence detection unit, and a control system.

Device Specifications

Item	Specification
Mechanical
Dimensions (W×D×H)	235 mm × 385 mm × 175 mm
Weight	5.6 kg
Electrical
Power	~220 V / 50 Hz, 255 W
Data Interface	2 × USB 2.0 (right side)
Environmental
Operating Conditions	10–30 ℃, 20%–80% RH
Storage & Transport	−20–55 ℃, 20%–80% RH
Altitude	< 2500 m
Noise	A‑weighted, < 60 dB
Sample
Sample Capacity	16 × 0.2 mL
Tube Type	Single tubes, 8‑tube strips, 16‑well blocks
Reaction Volume	15–100 μL
Thermal Performance
Heating/Cooling	Semiconductor heating / cooling
Temperature Range	4 ℃ – 99 ℃
Max Heating Rate	≥ 3.5 ℃/s
Avg Heating Rate	≥ 2.5 ℃/s
Max Cooling Rate	≥ 3.5 ℃/s
Avg Cooling Rate	≥ 2.5 ℃/s
Temperature Precision	≤ ±0.01 ℃
Temperature Accuracy	≤ ±0.1 ℃
Temperature Uniformity	≤ ±0.3 ℃
Optical Performance
Fluorescence Channels	2
Light Source	High‑brightness LED
Detector	High‑sensitivity, high‑SNR photodiode
Supported Probes/Dyes	Channel 1: 470/520 – FAM, SYBR Green Channel 2: 530/570 – HEX, JOE, VIC
Detection Sensitivity	1 copy
Linear Range	10⁰ – 10¹⁰ copies
Correlation Coefficient	≥ 0.999
Channel Crosstalk	None
Repeatability	≤ 1.0%
